¡½ Camera ¡¹ ¡¹ ¡¹ ¡¹
VCS-210 Camera
  • Images Sensor: 1/4" Sony Super HAD CCD
  • Number of Effective Pixels: 752 (H) x 582 (V)
  • Lens: 18X, 26X
  • Min. Illumination: 0.01 lx ~ 1.0 lx
  • S/N Ratio: More than 51dB
  • Certification¡GCE, FCC
VCS-220 Camera
  • Images Sensor: 1/4" Sony Super HAD CCD
  • Number of Effective Pixels: 752 (H) x 582 (V)
  • Lens: 18X, 26X, 36X
  • Min. Illumination: 0.01 lx ~ 3.0 lx
  • S/N Ratio: More than 50dB
VCS-300C Camera
  • Images Sensor: 1/3" Sony Super HAD CCD
  • Number of Effective Pixels: NTSC 811 (H) x 508 (V)
    Number of Effective Pixels: PAL 795 (H) x 596 (V)
  • Lens: 4.0 ~ 9.0mm Board Mount Auto IRIS
  • Min. Illumination: 0.1 lx F1.2
  • Certification¡GCE, FCC
VCS-800 Camera
  • Images Sensor: 1/3" Sony Super HAD CCD
  • Number of Effective Pixels: NTSC 811 (H) x 508 (V)
    Number of Effective Pixels: PAL 795 (H) x 596 (V)
  • Lens: C/CS Mount
  • Min. Illumination: 0.1 lx F1.2
  • Certification¡GCE, FCC
VCS-850 Camera
  • Images Sensor: 1/3" Interline Transfer
  • Number of Effective Pixels: NTSC 811 (H) x 508 (V)
    Number of Effective Pixels: PAL 795 (H) x 596 (V)
  • Lens: CS
  • Min. Illumination: 0.15 lx F1.2
  • S/N Ratio: More than 50dB
VCS-500 IR Camera
  • Images Sensor: 1/3" SONY CCD(SONY DSP)
  • Number of Effective Pixels: NTSC 811 (H) ¡Ñ 508 (V)
  • Min. Illumination: 0.1 Lux, F 1.2
VCS-310C Camera
  • Images Sensor: 1/3" Sony Super HAD CCD
  • Horizontal: 480 TV Lines
  • Lens: 3.6, 4.3 , 6, 8, 12 Board Lens
  • Min. Illumination: 0.1 lx F1.2
  • S/N Ratio: More than 50dB
  • Dome Size: 3.5" / 4.0" / 4.5" / 5.0"
SPT-M314 Camera
  • Images Sensor: 1/3" Interline Transfer Hyper HAD CCD
  • Horizontal: 570 TV Lines
  • Lens: C/CS Mount (Back-focus Adjustable)
  • Min. Illumination: 0.2 lx F1.2 (30 IRE, AGC ON)
    Min. Illumination: 0.5 lx F1.2 (50 IRE, AGC ON)
  • S/N Ratio: More than 45dB
